Wai Nickel Alloys is a leading manufacturer and supplier of titanium ball valves in Naypyidaw, Myanmar. Our titanium ball valves are engineered to provide exceptional strength, high strength and excellent corrosion resistance, making them ideal for complex industrial applications Known for their performance in extreme conditions these valves excel in harsh chemical, high pressure and high temperature applications. It is widely used in the chemical, aviation, marine and oil and gas industries. We adhere to strict quality standards to ensure each valve meets stringent industry requirements. Choose Wai Nickel Alloys for premium titanium ball valves that offer reliable performance and accuracy tailored to your specific needs.
Wai Nickel Alloys, based in Naypyidaw, Myanmar, stands out as a top manufacturer and supplier of **Titanium Ball Valves**. These valves are celebrated for their exceptional corrosion resistance, durability, and reliable performance in tough environments. Crafted with precision from high-quality titanium and cutting-edge manufacturing techniques, they guarantee leak-proof operation and a long lifespan. Wai Nickel Alloys ensures that their Titanium Ball Valves adhere to international quality standards, making them perfect for critical flow control applications in industries that prioritize reliability, strength, and chemical resistance.
| VALVE SIZE | 1/8″ TO 2″ / 6 MM TO 50 MM |
| STANDARD | ASTM B367, ASME B 16.10, BS EN 12266-1/API 598, ASME B 16.25, ASME B 16.5, BS1414/API 600, ASME B 16.34 |
| THREAD | BSPP, JIC, BSPT, METRIC, NPT, UNF |
| FUNCTION | 3 WAY, 2 WAY, 5 WAY, 4 WAY, |
| CONNECTION | THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE |
| PRESSURE RATING | 3000 PSI, 15000 PSI, 6000 PSI, 1500 PSI, 10000 PSI, 20000 PSI |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| EQUIVALENT BRANDS | PARKER, OLIVER VALVES, SWAGELOK, HAMLET, DK-LOK, HOKE |
| SEAL RING MATERIAL | PVDF, PTFE, PEEK, DELRIN, GRAPHITE |
| MEDIA | AIR, HYDRAULIC OIL, GAS, WATER, HOT WATER , STEAM, SEA WATER , COLD WATER ,CHEMICAL |
| BODY TYPE | BAR STOCK |
| MEDIA TEMPERATURE | (-120* C – 500*C )RANGE AS PER PRESSURE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Ti | C | O | H | N | Fe | Al | V |
| Ti Grade5 | 90 min | – | 0.2 max | – | – | 0.25 max | 6 min | 4 min |
| Ti Grade2 | 99.2 min | 0.1 max | 0.25 max | 0.015 max | 0.03 max | 0.3 max | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
Typically, **Titanium Ball Valves** are constructed from commercially pure titanium (Grade 2) or titanium alloys like Grade 5 and Grade 12, tailored to the specific operating conditions. Titanium strikes a remarkable balance between high strength, lightweight design, and outstanding corrosion resistance, even in challenging environments such as seawater, chlorine, and acidic solutions. These valves offer excellent mechanical stability, a smooth flow path, and require minimal maintenance, maintaining their integrity under high-pressure and high-temperature situations.
Contact us to get a quick quote for your requirement.
You’ll find **Titanium Ball Valves** widely used across various sectors, including chemical processing, marine, desalination, oil and gas, and power generation. They excel at managing corrosive fluids like acids, chlorides, and seawater. Moreover, they are also utilized in the aerospace and pharmaceutical industries, where purity and corrosion resistance are paramount. These valves are commonly found in pipelines, heat exchangers, and pressure systems, ensuring efficient flow control, operational safety, and long-lasting performance, even in the most demanding industrial settings.
