Located in the heart of Naypyidaw, Wai Nickel Alloys has built a strong reputation as a dedicated manufacturer and supplier of high-performance components, with a particular expertise in Hastelloy flanges. We understand that in demanding industrial settings, the integrity of every connection is paramount. That’s why we focus on delivering flanges that are meticulously crafted to offer exceptional reliability and longevity, ensuring your operations run smoothly and safely, even under the most challenging conditions.
The strength of our Hastelloy flanges comes from their unique composition, primarily a blend of nickel, molybdenum, and chromium. This specific recipe grants them outstanding mechanical properties, including high tensile strength and excellent resistance to creep. Perhaps most importantly, they maintain remarkable toughness and structural integrity across a wide range of temperatures, from extreme heat to cryogenic conditions, preventing brittleness and failure when it matters most.
| Specifications | Hastelloy Flanges |
|---|---|
| ASME B16.5 Hastelloy C276 Flange size range | 1/2″ (15 NB) to 48″ (1200NB) DN10~DN5000 |
| Hastelloy Flanges Standards | ANSI/ASME B16.5, B16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, GOST Flanges. |
| Hastelloy C276 Flange Standard ANSI | Class 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS |
| Hastelloy C276 Flange Standard DIN | 6Bar 10Bar 16Bar 25Bar 40Bar / PN6 PN10 PN16 PN25 PN40, PN64 |
| Hastelloy C276 Flange Standard JIS | 5K, 10 K, 16 K 20 K, 30 K, 40 K, 63 K |
| Hastelloy C276 Flange Standard UNI | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Hastelloy C276 Flange Standard EN | 6Bar 10Bar 16Bar 25Bar 40Bar |
| Main Types | Forged / Threaded / Screwed / Plate |
| Flange supporting material | Gasket, Ring Joint, Flange Bolts |
| Hastelloy C276 Pipe Flanges Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc |
| Most common types of Hastelloy C276 Flanges |
|
| Production technique |
|
| Connect Type/ Flange Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF), Large Male-Female (LMF), Lap-Joint Face (LJF), Small Male-Female (SMF), Small Tongue, Large Tongue & Groove |
| Special design | As per your drawing AS, ANSI, BS, DIN and JIS 15 NB (1/2″) to 200 NB (8″) Equal and Reducing Configurations Hastelloy C276 Threaded Flange, Socketweld Flange, Slip-On Flange, Blind Flange, Weld Neck Flange |
| Grade | Hastelloy C22 |
|---|---|
| C | 0.010 max |
| Mn | 0.50 max |
| Si | 0.08 max |
| S | 0.02 max |
| Co | 2.50 max |
| Ni | 50.015 min |
| Cr | 20.00 – 22.50 |
| Fe | 2.00 – 6.00 |
| Mo | 12.50 – 14.50 |
| P | 0.02 max |
| Density | 8.89 g/cm3 |
| Melting Point | 1370 °C (2500 °F) |
| Tensile Strength | Psi – 1,15,000 , MPa – 790 |
| Yield Strength (0.2%Offset) | Psi – 52000 , MPa – 355 |
| Elongation | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Flanges in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
These robust characteristics make Hastelloy flanges indispensable in industries where failure is not an option. You will find them creating secure connections in chemical processing plants handling corrosive acids, in offshore oil and gas equipment resisting seawater corrosion, and in pollution control scrubbers. Their ability to withstand severe environments also makes them a preferred choice for nuclear power applications and in the aerospace sector, proving their value wherever exceptional corrosion resistance and unwavering performance are required.
