Based in the heart of Naypyidaw, Wai Nickel Alloys has built a strong reputation as a trusted source for high-performance materials, specializing in the supply and manufacture of superior Hastelloy ball valves. We understand that in demanding environments, reliability is everything, which is why we focus on providing components that offer exceptional durability and resistance. Our commitment is to deliver solutions that not only meet but exceed the rigorous demands of modern industry, ensuring our clients can operate with confidence and efficiency.
The exceptional performance of Hastelloy ball valves stems from their unique nickel-chromium-molybdenum composition, which grants them a formidable defense against a wide range of corrosive threats, including pitting and cracking. This advanced alloy is engineered to maintain its strength and integrity even when exposed to extreme temperatures and high pressures. The result is a valve that is not just resistant, but truly resilient, offering a long service life and dependable operation under the most challenging conditions, which minimizes downtime and maintenance needs.
| VALVE SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.34, ASTM A494/ASME SA494, ASME B 16.5, ASME B 16.10, BS EN 12266-1/API 598, BS1414/ API 600, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | Mn | C | Co | S | Si | Cr | Ni | Mo | Fe | W |
| Alloy C22 | 0.50 max | 0.010 max | 2.5 max | 0.02 max | 0.08 max | 20 – 22.5 | Bal | 12.5 – 14.5 | 2 – 6 | 2.5 – 3.5 |
| Alloy C276 | 1.0 max | 0.010 max | 2.5 max | 0.03 max | 0.08 max | 14.5 – 16.5 | Bal | 15 – 17 | 4 – 7 | 3 – 4.5 |
| Element | Melting Point | Yield Strength (0.2%Offset) | Density | Tensile Strength | Elongation |
| Alloy C22 | 1399 °C (2550 °F) | Psi – 45000 , MPa – 310 | 8.69 g/cm3 | Psi – 1,00,000 , MPa – 690 | 45 % |
| Alloy C276 | 1370 °C (2500 °F) | Psi – 52,000 , MPa – 355 | 8.89 g/cm3 | Psi – 1,15,000 , MPa – 790 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Ball Valve in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You will typically find these robust valves hard at work in industries where failure is not an option. They are essential in chemical processing plants, managing aggressive acids and solvents, and in pharmaceutical production where purity is paramount. Their resistance makes them ideal for oil and gas applications, particularly in offshore and sour service environments, as well as in pollution control and power generation systems. Essentially, wherever highly corrosive media or extreme conditions are present, Hastelloy ball valves provide the critical, reliable sealing required for safe and continuous operation.
