Based in the heart of Naypyidaw, Wai Nickel Alloys has built a strong reputation as a trusted manufacturer and supplier of high-performance materials, with a particular focus on the demanding needs of modern industry. Our dedication to precision engineering and stringent quality control is perfectly exemplified by our line of Incoloy valves, which are designed to perform reliably under the most challenging conditions, ensuring longevity and safety for your critical operations.
The exceptional strength of Incoloy valves comes from their unique composition, primarily a blend of nickel, chromium, and iron, with strategic additions of molybdenum and copper. This specific recipe grants them outstanding mechanical properties, including remarkable tensile strength and excellent resistance to creep and fatigue. They maintain their structural integrity even when exposed to intense pressure and extreme temperatures, making them far superior to standard alternatives.
| Material | Incoloy |
|---|---|
| Seal Material | PTFE/ RPTFE |
| Working Pressure | 1.6 – 6.4Mpa |
| Working Temperature | -29°C — +180°C |
| Availabe Size | 1/2″-4″,(DN15-DN100) |
| Available Connection | BSP/ BSPT/ NPT/ Flanged/ Welded |
| Nominal Pressure | P10/PN16 |
| Operation | Manual,Pneumatic, Electric |
| Suitable Medium | Water,Sewage,Seawater,Gas,Food,Oils,etc |
| Standards | GB9112,DIN2501,BS4504,ISO2084,ANSI125 |
| Applications | Water, Oil, Gas, |
| Nominal Diameter | DN40-DN300 handle lever DN350-DN1200 gear box |
| Operation Temperature | -10°C~150°C |
| Grade | Ni | Fe | Cr | Cu | Mn | S | Si | Ti | Al | C |
| Alloy 800 | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .1 max |
| Alloy 800HT | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .25-.60 | .85-1.20 | .06-.10 max |
| Alloy 800H | 30.0-35.0 | 39.5 min | 19.0-23.0 | .75 max | 1.5 max | .015 max | 1.0 max | .15-.60 | .15-.60 | .05-.10 max |
| Density | Yield Strength (0.2%Offset) | Melting Point | Tensile Strength | Elongation |
| 7.94 g/cm3 | Psi – 30,000 , MPa – 205 | 1350-1400 ℃ | Psi – 75,000 , MPa -520 | 30 – 35 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Valve in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Because of their robust nature, Incoloy valves are indispensable in industries where failure is not an option. You will find them controlling corrosive and high-temperature flows in chemical processing plants, managing sour gas in oil and gas extraction, and within the complex systems of power generation facilities. Their reliability also makes them a preferred choice for marine and offshore applications, where they consistently withstand aggressive environments, protecting both equipment and personnel.
