Wai Nickel Alloys, a leading manufacturer and supplier located in Naypyidaw, Myanmar, specializes in precision-engineered Super Duplex Steel Manifold Valves. These valves are crafted for exceptional strength, corrosion resistance, and performance in tough industrial settings. With cutting-edge technology and rigorous quality control, they guarantee leak-free operation, impressive pressure handling, and a long lifespan. Super Duplex Manifold Valves are particularly resistant to pitting, crevice corrosion, and stress corrosion cracking, even in environments rich in chlorides. Perfect for critical process control systems, they offer outstanding reliability and durability across industries like oil & gas, chemical processing, marine, and power generation.
Super Duplex Steel Manifold Valves are mainly made up of Chromium (24–26%), Nickel (6–8%), Molybdenum (3–5%), and balanced Iron, along with controlled amounts of Nitrogen, Manganese, and Silicon. This unique dual-phase microstructure provides high tensile strength (800–1000 MPa), yield strength (~550 MPa), and remarkable toughness. The valves are known for their excellent resistance to chloride stress corrosion, oxidation, and fatigue cracking. They maintain their shape and mechanical integrity at both high and low temperatures, making them perfect for critical flow control systems that operate under extreme pressure and in corrosive industrial environments.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Manifold Valve in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Manifold Valves are extensively utilized in industries that require precise flow control and strong corrosion resistance. In the oil and gas industry, you’ll find them on offshore platforms, in subsea systems, and in refinery process lines that are exposed to seawater and harsh chemicals. The chemical and petrochemical sectors rely on them for heat exchangers, pressure systems, and fluid handling setups. In the marine sector, they are ideal for desalination plants and shipboard systems. Additionally, Super Duplex Manifold Valves are used in various other applications where reliability and durability are crucial.
