Wai Nickel Alloys, a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, specializes in top-notch Duplex Steel Ball Valves that are built to perform exceptionally well in tough industrial settings. These valves are crafted with precision to ensure smooth operation, reliable sealing, and a long lifespan, even when faced with high pressure and temperature. Made from high-quality Duplex Steel, they resist pitting, crevice corrosion, and stress corrosion cracking. Duplex Ball Valves are perfect for managing the flow of liquids and gases in various applications, including marine, chemical, oil & gas, and desalination.
Duplex Steel Ball Valves are made up of Chromium (21–23%), Nickel (4.5–6.5%), Molybdenum (2.5–3.5%), and a balanced amount of Iron, along with small traces of Nitrogen, Manganese, and Silicon. Their duplex microstructure gives them impressive tensile strength (700–900 MPa) and yield strength (~450 MPa), all while ensuring excellent toughness and ductility. These valves boast outstanding corrosion resistance in environments rich in chlorides and acids, along with remarkable oxidation resistance and dimensional stability across varying temperatures. Their robust mechanical strength, paired with resistance to stress and erosion, makes them perfect for high-pressure fluid control systems.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| ELEMENT | DUPLEX 31803 | DUPLEX 2205 |
|---|---|---|
| NI | 4.50 – 6.50 | 4.50 – 6.50 |
| C | 0.030 max | 0.030 max |
| N | 0.14 – 0.20 | 0.08 – 0.20 |
| P | 0.030 max | 0.030 max |
| MN | 2.00 max | 2.00 max |
| CR | 22.0 – 23.0 | 21.0 – 23.0 |
| S | 0.020 max | 0.20 max |
| MO | 3.0 – 3.5 | 2.50 – 3.50 |
| SI | 1.00 max | 1.00 max |
| FE | 63.72 min | 63.54 min |
| Grade | UTS (MPa) | % Elongation | Hardness(BHN) | YS (MPa) |
| 31803 | 620 min. | 25 min. | 293 max. | 450 min. |
| 2205 | 655 min. | 25 min. | 293 max. | 450 min. |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Duplex Ball Valve in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Duplex Steel Ball Valves are widely utilized in industries that demand strong, corrosion-resistant components for flow control. In the oil and gas industry, they are particularly suited for offshore platforms, pipelines, and refineries that deal with harsh chemicals and seawater. The chemical and petrochemical sectors rely on them for process control in corrosive settings. They also play a crucial role in marine engineering, desalination plants, and power generation systems where durability is key. Additionally, Duplex Ball Valves are used in pulp and paper mills, showcasing their versatility across various applications.
