Strategically located in the capital city of Naypyidaw, Wai Nickel Alloys has built a strong reputation as a trusted manufacturer and supplier of high-performance materials. We take particular pride in our expertise with Incoloy forged fittings, which are engineered to meet the most demanding industrial challenges. Our commitment goes beyond mere supply; we work closely with our clients to ensure they receive components that offer exceptional reliability and longevity, backed by our deep understanding of the specific conditions these critical parts will face.
The exceptional performance of Incoloy forged fittings stems from their sophisticated composition, primarily a nickel-iron-chromium alloy enhanced with elements like molybdenum and copper. This unique blend grants them outstanding mechanical properties, including high tensile strength and remarkable resistance to creep and fatigue. They retain this structural integrity even when subjected to extreme temperatures and intense pressure, making them incredibly durable components built for the long haul in punishing environments.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Incoloy 800, 800H, 800HT, 825, 925 Forged Fittings
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Incoloy Forged Fittings | 7.94 g/cm3 | 1385 °C (2525 °F) | Psi – 75,000 , MPa – 520 | Psi – 30,000 , MPa – 205 | 30 % |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Incoloy Forged Fittings | 0.10 max | 1.50 max | 1.00 max | 0.015 max | 0.75 max | 39.50 min | 30.00 – 35.00 | 19.00 – 23.00 | 0.15 – 0.60 | 0.15 – 0.60 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Forged Fittings in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Incoloy forged fittings are indispensable in industries where failure is not an option. You will find them performing critical roles in chemical processing plants, handling corrosive acids and solvents, and within oil and gas installations confronting sour service environments. They are equally vital in pollution control scrubbers, marine engineering applications, and nuclear power systems. Essentially, wherever severe corrosion and high temperatures are a constant threat, these fittings provide the dependable, leak-proof connections needed for safe and continuous operation.
