Based in the heart of Naypyidaw, Wai Nickel Alloys has built a strong reputation as a trusted manufacturer and supplier of high-performance materials, with a particular focus on Incoloy pipe fittings. We understand that the integrity of your piping systems is critical, which is why we are dedicated to providing components that stand up to the most demanding industrial environments. Our commitment is to deliver not just a product, but a reliable solution that supports the ambitious growth and complex projects taking shape across Myanmar and beyond.
The exceptional strength of Incoloy pipe fittings comes from a sophisticated nickel-iron-chromium composition, often enhanced with elements like molybdenum and copper. This careful balance gives these fittings outstanding mechanical properties, including high tensile strength and excellent resistance to creep and stress rupture, even at elevated temperatures. They are engineered to maintain their structural integrity under significant pressure and thermal stress, ensuring a long service life and dependable performance in situations where ordinary materials would quickly fail.
Specifications : ASTM B366 / ASME SB366
Size : Seamless Inconel / Incoloy Butt Weld Fittings: 1/2″ – 10″
Welded Inconel / Incoloy Butt Weld Fittings: 1/2″ – 48″
Dimensions : ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504, BS4504, BS1560, BS10
ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Thickness : SCH10, SCH20, SCH30, STD SCH40, SCH60, XS, SCH 80, SCH 100, SCH 120, SCH 140, SCH 160, XXS available with NACE MR 01-75
Types : Seamless / Welded / Fabricated
Bending Radius : R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr | Al | Ti |
| Inconel Pipe Fittings | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 | – | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel Pipe Fittings | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Incoloy Pipe Fittings in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Incoloy pipe fittings are indispensable in industries where equipment is pushed to its limits. You’ll find them hard at work in chemical processing plants handling corrosive acids, in oil and gas extraction facing extreme pressures, and in pollution control scrubbers. They are also essential in the power generation sector, particularly in nuclear and fossil fuel plants, for their ability to withstand high temperatures and aggressive environments. Essentially, wherever corrosion and heat are a concern, Incoloy fittings provide the durability needed for safe and continuous operation.
