At Wai Nickel Alloys, based in Naypyidaw, Myanmar, we specialize in high-quality titanium forged fittings designed for demanding industrial applications. Our titanium fittings, known for their exceptional strength, corrosion resistance, and lightweight properties, are meticulously engineered to meet stringent industry standards. As a leading manufacturer and supplier, we ensure that each product delivers unparalleled performance and reliability. Trust us for top-tier titanium forged fittings that enhance the durability and efficiency of your systems.
Wai Nickel Alloys, based in Naypyidaw, Myanmar, has earned a solid reputation as a reliable manufacturer and supplier of **Titanium Forged Fittings**. These fittings are celebrated for their remarkable strength, resistance to corrosion, and long-lasting durability. Crafted with precision from high-quality titanium and utilizing advanced forging techniques, they guarantee exceptional mechanical integrity and precise dimensions. Wai Nickel Alloys is dedicated to producing Titanium Forged Fittings that adhere to international standards, ensuring dependable and enduring performance even in the most challenging industrial settings.
Specifications : ASTM B381 / ASME SB381
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type : Socketweld Fittings, Screwed-Threaded Fittings
Grades : Titanium Gr. 2 Titanium Gr. 5
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
**Titanium Forged Fittings** are constructed from commercially pure titanium (Grade 2) or various titanium alloys like Grade 5, Grade 7, and Grade 12, tailored to meet specific application needs. The material boasts an impressive strength-to-weight ratio, with tensile strength varying from 345 MPa (Grade 2) to 895 MPa (Grade 5). These fittings excel in resisting oxidation, seawater, and chemical corrosion, maintaining their mechanical stability even under high pressure and temperature. Thanks to titanium’s excellent formability, weldability, and toughness, it’s the perfect choice for precision-forged components.
Contact us to get a quick quote for your requirement.
You’ll find **Titanium Forged Fittings** in a variety of industries, including chemical processing, marine, power generation, desalination, and oil & gas. They’re particularly well-suited for use in heat exchangers, pipelines, reactors, and offshore platforms where strength and corrosion resistance are paramount. Their lightweight and non-reactive nature also makes them ideal for aerospace, medical, and pharmaceutical applications. With Titanium Forged Fittings, you can count on leak-proof connections, outstanding performance, and a longer service life, even in harsh and corrosive environments.
