Wai Nickel Alloys, a reputable manufacturer and supplier located in Naypyidaw, Myanmar, focuses on crafting high-performance Super Duplex Steel Ball Valves known for their outstanding durability, corrosion resistance, and operational efficiency. Made from top-quality Super Duplex alloys, these valves are engineered to endure extreme pressures, temperatures, and harsh environments. Their well-balanced austenitic-ferritic microstructure offers excellent protection against pitting, crevice corrosion, and stress corrosion cracking. Super Duplex Ball Valves guarantee leak-free performance, smooth operation, and a long lifespan, making them perfect for industries like oil & gas, marine, chemical, and desalination applications.
Super Duplex Steel Ball Valves consist of Chromium (24–26%), Nickel (6–8%), Molybdenum (3–4%), with Iron making up the balance, along with controlled amounts of Tungsten, Copper, and Nitrogen. This unique alloy delivers impressive tensile strength (800–1000 MPa) and yield strength (~550 MPa), ensuring remarkable toughness and resistance to fatigue. The dual-phase structure significantly boosts resistance to chloride-induced corrosion, oxidation, and erosion, even under high-pressure and high-temperature conditions. These valves maintain their shape and sealing performance, providing excellent weldability and machinability, making them ideal for complex fluid control systems in demanding industrial settings.
| VALVES SIZE | 6 MM TO 50 MM and 1/8″ TO 2″ |
| STANDARD | ASME B 16.10, BS1414/API 600, ASME B 16.5, BS EN 12266-1/API 598, ASME B 16.34, ASTM A890 4A, ASME B 16.25 |
| CONNECTION | TUBE END, THREADED, SOCKET WELD, BUTT WELD, FLANGED, WELD NIPPLE, SAE |
| THREAD | METRIC, BSPP, NPT, JIC, BSPT, UNF |
| FUNCTION | 2 , 5 , 4 , 3 WAY, |
| MATERIAL OF SEAL RING | PVDF, DELRIN, GRAPHITE, PTFE, PEEK, |
| PRESSURE RATING | 15000 , 3000, 1500 , 10000, 6000 , 20000 PSI |
| TEMPERATURE OF MEDIA | (-120* C – 500*C ) AS LIKE PRESSURE RANGE |
| STANDARD | DIN , ISO , API , ANSI , AWWA , ASME , MSS |
| MEDIA | AIR, CHEMICAL, GAS, WATER, STEAM, HOT WATER , HYDRAULIC OIL, COLD WATER, SEA WATER |
| TYPE OF BODY | BAR STOCK |
| EQUIVALENT BRANDS | OLIVER VALVES, PARKER, SWAGELOK, HAMLET, DK-LOK, HOKE |
| PACKING DETAILS | WOODEN PALLET, BOX PACKING |
| Grade | S32760 | S32750 |
| Mn | 1.00 max | 1.20 max |
| Fe | 57.61 min | 58.095 min |
| C | 0.05 max | 0.030 max |
| Si | 1.00 max | 0.80 max |
| S | 0.010 max | 0.020 max |
| P | 0.030 max | 0.035 max |
| Cr | 24.00 – 26.00 | 24.00 – 26.00 |
| Ni | 6.00 – 8.00 | 6.00 – 8.00 |
| Mo | 3.00 – 4.00 | 3.00 – 5.00 |
| N | 0.20 – 0.30 | 0.24 – 0.32 |
| Melting Point (°C) | 1350 |
| Density (lb/in 3) | 0.281 |
| Density (g/cm 3) | 7.8 |
| Melting Point (°F) | 2460 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Super Duplex Ball Valve in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Super Duplex Steel Ball Valves find extensive use in industries that require exceptional corrosion resistance and mechanical strength. In the oil and gas sector, they are perfect for offshore platforms, refineries, and subsea pipelines that handle corrosive fluids. The chemical and petrochemical industries rely on them for process control systems, heat exchangers, and reactors. Additionally, they are widely utilized in marine engineering, desalination plants, and power generation systems due to their impressive resistance to harsh conditions.
