Home > MP35N Sheets and Plates
Wai Nickel Alloys, a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, specializes in top-quality MP35N Sheets and Plates. These products are celebrated for their remarkable strength, resistance to corrosion, and long-lasting durability. Crafted from a high-performance nickel-cobalt-chromium-molybdenum alloy, they excel in extreme conditions. The MP35N Sheets and Plates boast impressive mechanical properties and are highly resistant to hydrogen embrittlement, stress corrosion cracking, and crevice corrosion. They find their place in demanding industries like aerospace, medical, marine, and oil and gas, where strength, toughness, and reliability are absolutely essential. Wai Nickel Alloys is committed to delivering consistent quality and precision engineering.
MP35N Sheets and Plates are composed of about 35% Nickel, 35% Cobalt, 20% Chromium, and 10% Molybdenum, along with small amounts of Iron, Carbon, and Silicon. This distinctive alloy achieves a tensile strength that surpasses 200 ksi (1379 MPa) while also offering excellent ductility. It retains high mechanical integrity even after age-hardening and exposure to harsh environments. MP35N is known for its outstanding resistance to corrosion and oxidation, as well as its non-magnetic properties when annealed. Its unique blend of ultra-high strength, toughness, and biocompatibility makes it ideal for both industrial and medical applications.
| Standard Specification : | ASTM F562 / ASME SF562 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condtion | Ultimate Tensile Strength ksi | 0.2 % Yield Strength ksi | Elongation % | Reduction of Area % | Hardness HRC |
| MP35N AMS 5844 | Solution Heat Treated and Work Strengthened | 255 | 225 | 12 | 50 | 45 |
| MP35N AMS 5845 | Solution Heat Treated and Work Strengthened and Aged | 260 | 230 | 8 | 35 | 38 min |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
MP35N Sheets and Plates are extensively utilized in the aerospace sector for creating fasteners, springs, and engine components that face high stress and temperature. In the medical field, they are used for surgical implants, orthopedic devices, and catheters, thanks to their biocompatibility and corrosion resistance. The oil and gas industry relies on MP35N for downhole tools, pressure housings, and valve components that must withstand extreme conditions. Furthermore, these sheets and plates are also employed in marine engineering, defense, and chemical processing equipment, where durability and reliability are crucial.
