Wai Nickel Alloys is a trusted manufacturer and supplier based in Naypyidaw, Myanmar, known for supplying high quality nickel alloys and steel to various industries worldwide Specializing in high performance materials, the company offers a wide range of products, including premium manganese bronze sheets and plates, known for exceptional durability, corrosion resistance and durability Due to committed to accuracy, innovation and customer satisfaction, Wai Nickel Alloy is the preferred partner for businesses seeking reliable high quality steel solutions
Wai Nickel Alloys stands out as a reliable manufacturer and supplier based in Naypyidaw, Myanmar, specializing in top-notch Manganese Bronze Sheets and Plates designed for heavy-duty engineering and industrial needs. The company prides itself on delivering products that boast impressive strength, wear resistance, and durability against corrosion, all thanks to their meticulous manufacturing processes and rigorous material testing. Their manganese bronze sheets and plates come in a variety of thicknesses and specifications, tailored to meet the requirements of marine, mechanical, power, and industrial sectors. Renowned for their long service life, high load-bearing capacity, and excellent machinability, Wai Nickel Alloys offers dependable bronze solutions for components that face friction, seawater, and tough operating conditions.
| Standard | JIS H3250-2006,ASTM B152M,GB/T2040-2008,ASTM B36,ASTM B194,ASTM B888, ASTM B19,ASTM B122,etc |
| Thickness | 0.1-120mm |
| Width | 2-2500mm |
| Length | 1m,2m,3m,6m,or as required |
| Surface | mill,polished,bright,mirror,hair line,brush,checkered,antique,sand blast,etc |
| Container size | 20ft GP:5898mm(Length)x2352mm(Width)x2393mm(High) 40ft GP:12032mm(Length)x2352mm(Width)x2393mm(High) 40ft HC:12032mm(Length)x2352mm(Width)x2698mm(High) |
| Application | Brass plate has a high corrosion resistance, and have good plasticity,in the air easy to cold and hot pressure processing,easy to welding, forging and tin, no stress corrosion cracking the tendency. |
| Cu(1) | Al | Fe | Pb | Mn | Sn | Zn | |
| Min./Max. | 57.0-60.0 | .25 | .8-2.0 | .20 | .05-.50 | .50-1.5 | Rem. |
| Nominal | 58.5 | – | 1.4 | – | .10 | 1.0 | 39.0 |
| ensile Strength, min | Yield Strength, at 0.5% extension under load, typ | Elongation, in 2 in. or 50 mm typ | Brinell Hardness (500 kg load) | Remarks | ||
|---|---|---|---|---|---|---|
| ksi | MPa | ksi | MPa | % | typical BHN | |
| 65 | 448 | 25 | 172 | 20 | 90 | |
Manganese Bronze Sheets and Plates are crafted from a blend of copper, zinc, and manganese, with small amounts of iron, aluminum, and occasionally lead to enhance machinability. These alloys are known for their high tensile strength, remarkable hardness, and outstanding resistance to wear and shock loading. They maintain robust mechanical stability even in corrosive environments, particularly in seawater and industrial settings. With their toughness and fatigue resistance, manganese bronze sheets and plates are perfect for components that experience continuous movement, heavy loads, and abrasive contact.
Contact us to get a quick quote for your requirement.
These sheets and plates find extensive use in applications that demand high strength and corrosion resistance. In the marine industry, they are essential for ship hardware, propeller components, shafting parts, and underwater fasteners. Engineering and industrial sectors utilize them for gears, bearings, bushings, wear plates, pump components, and hydraulic equipment. They also play a crucial role in heavy machinery, power transmission systems, oil and gas equipment, bridges, and architectural hardware where durability is key. Their ability to endure harsh conditions, mechanical stress, and ongoing friction makes manganese bronze sheets and plates a trusted choice for lasting structural and mechanical performance.
