Wai Nickel Alloys stands as a key manufacturer and supplier in Naypyidaw, Myanmar, dedicated to providing high-performance materials for demanding industries. We specialize in Alloy C263 sheets and plates, delivering products that meet the most rigorous international standards. Our commitment is not just to supply metal, but to provide reliable solutions that empower our clients’ most critical projects. We understand that behind every sheet is an application where performance and durability are non-negotiable, and we build that trust into everything we produce.
The strength of Alloy C263 lies in its specific composition, primarily nickel-chromium with additions of cobalt and molybdenum. This blend gives the sheets and plates exceptional mechanical properties, including high tensile strength and outstanding resistance to creep and fatigue, even when exposed to extreme temperatures. It’s a material engineered to perform under stress, maintaining its integrity in environments that would cause other alloys to fail. This robust combination makes it a go-to choice for applications where both heat and mechanical load are significant factors.
| Standard Specification : | AMS 5872 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | Ni | Co | Cr | Mo | Ti | Fe | Mn | Al | Si | Cu | C | B | S |
| Alloy C263 | 49 | 19-21 | 19-21 | 5.60-6.10 | 1.90-2.40 | 0.70 | 0.60 | 0.60 | 0.40 | 0.20 | 0.040 – 0.080 | 0.0050 | 0.0070 |
| Material | Temp °C | Yield Strength (Mpa) | Tensile Strength (Mpa) | Elongation % | Hardness HRC |
|---|---|---|---|---|---|
| Alloy C263 Solution Treated (AMS 5872 / BS HR206) | RT | – | – | – | 22.5 max |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | RT | 580 (typical) | 973 (typical) | 39 – | |
| Alloy C263 Heat Treated (AMS 5872 / BS HR206 | 780 | 403 (min) | 541 (min) | 9 | – |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Alloy C263 Sheets and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
You will find Alloy C263 sheets and plates hard at work in the heart of aerospace engineering, forming essential components for jet engines like combustion chambers and turbine casings. Its reliability also makes it indispensable in the power generation sector for gas turbine assemblies. Beyond these high-stakes fields, it serves critical roles in industrial gas turbines and various high-temperature chemical processing equipment. Essentially, wherever intense heat and corrosive conditions converge, this alloy provides the necessary resilience to ensure long-lasting, safe, and efficient operation.
