Wai Nickel Alloys is a reputable manufacturer and supplier of top-notch Inconel 718 Stud Bolts, proudly based in Naypyidaw, Myanmar. Known for its dedication to precision engineering and high-quality materials, the company provides corrosion-resistant, high-performance fasteners that are built to handle tough industrial applications. With cutting-edge production facilities and a talented technical team, Wai Nickel Alloys guarantees that each stud bolt meets international standards for strength, durability, and reliability. Catering to industries like aerospace, petrochemical, power generation, and marine, the company consistently raises the bar for excellence in specialty alloy products throughout Myanmar and beyond.
Inconel 718 Stud Bolts are primarily made up of nickel (50–55%), chromium (17–21%), iron (the balance), along with niobium, molybdenum, and small amounts of titanium and aluminum. This distinctive blend offers remarkable strength, oxidation resistance, and outstanding corrosion resistance, even at elevated temperatures. The alloy boasts impressive mechanical properties, featuring tensile strength exceeding 1350 MPa and yield strength around 1100 MPa. Its exceptional creep resistance and toughness, even in cryogenic conditions, make Inconel 718 the go-to choice for critical fastening applications that face extreme thermal and mechanical stress.
| Specification | ASTM F468, B637 / ASME SF468, SB637 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 718 Stud Bolts in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 718 Stud Bolts are commonly found in high-stress environments where superior strength and corrosion resistance are a must. They’re perfect for aerospace engines, gas turbines, heat exchangers, nuclear reactors, and chemical processing equipment. In the oil and gas sector, these bolts secure flanges and pressure vessels that endure harsh, high-temperature, and corrosive conditions. Their ability to maintain mechanical integrity across a wide range of temperatures makes them vital for power generation and marine applications. With exceptional resistance to oxidation and stress-corrosion cracking, Inconel 718 Stud Bolts promise long-lasting performance and reliability, even in the most demanding operational environments.
