Wai Nickel Alloys stands out as a top-notch manufacturer and supplier of Inconel 625 Stud Bolts in Naypyidaw, Myanmar. They focus on delivering high-quality fastening solutions that are specifically designed for high-performance applications. These stud bolts are crafted to provide exceptional resistance to heat, corrosion, and oxidation, even in the toughest industrial environments. Thanks to their precision engineering and commitment to international standards, Wai Nickel Alloys guarantees impressive dimensional accuracy and durability. Their Inconel 625 Stud Bolts have earned a solid reputation across various industries, including aerospace, marine, oil and gas, power generation, and chemical processing, all for their unmatched strength and long-lasting reliability.
Inconel 625 Stud Bolts are primarily made up of nickel (at least 58%) and chromium (20–23%), with added molybdenum (8–10%) and niobium (3.15–4.15%) to boost their mechanical strength and corrosion resistance. This unique composition gives them remarkable resistance to oxidation, pitting, and crevice corrosion. On the mechanical side, the alloy boasts a tensile strength of around 930 MPa and a yield strength of 517 MPa, while maintaining excellent toughness, ductility, and fatigue resistance. These characteristics ensure they perform exceptionally well under high-pressure and high-temperature conditions.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 625 | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 58.0 min | 20.0 – 23.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 625 Stud Bolts in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 625 Stud Bolts are widely utilized in industries that demand strong fastening solutions in extreme conditions. They are perfect for aerospace engine assemblies, exhaust systems, and turbine components due to their impressive strength and resistance to oxidation. In the marine and offshore sectors, you’ll find them in seawater piping, pumps, and structural connections. The oil and gas industry relies on them for refinery equipment, heat exchangers, and offshore platforms. Moreover, chemical processing and power generation plants use these stud bolts in reactor vessels and heat-treating systems, ensuring reliability and stability in their demanding operations.
