Wai Nickel Alloys stands out as a top-notch manufacturer and supplier of high-quality Inconel 600 Stud Bolts, proudly based in Naypyidaw, Myanmar. The company has earned a solid reputation for its dedication to providing fasteners made from nickel alloys that are not only corrosion-resistant but also heat-resistant and incredibly strong, all while adhering to international standards. Thanks to their state-of-the-art production facilities, precision engineering, and rigorous quality checks, Wai Nickel Alloys guarantees that every product is reliable, durable, and performs exceptionally well. Their Inconel 600 Stud Bolts are trusted by various industries, including petrochemical, marine, aerospace, and power generation, where outstanding resistance to heat, oxidation, and chemical corrosion is crucial for safe and efficient operations.
These Inconel 600 Stud Bolts are primarily made up of nickel (at least 72%), chromium (14–17%), and iron (6–10%), along with small amounts of manganese, silicon, and carbon. This unique alloy offers remarkable resistance to oxidation, corrosion, and chloride-ion stress cracking. It boasts impressive mechanical strength, with a tensile strength of around 655 MPa and a yield strength of about 310 MPa. Inconel 600 maintains its structural integrity even at high temperatures, reaching up to 1150°C, and showcases excellent toughness and metallurgical stability, making it perfect for high-temperature fastening applications.
| Specifications | ASTM A166 / ASME A166 |
| Standard | DIN, ISO ,JIS ,GB, IS, BS, ASTM and all International Standards |
| Size | M3 – M100 | 3/6″ – 4″ | Custom Sizes |
| Length | 3 mm – 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Head | Hex, Square, Round, Hex flange, Flat, T-head & Triangular etc. |
| Neck type | Hex, Square, Triangular, Oval & Knurled etc. |
| Surface Treatment | Passivation /plain |
| Others Factor | OEM, ODM, ±0.03MM tolerance |
| Manufacturing Process | Wire Drawing, Cold Heading, Insert tapping, Heat Treatment, Surface Plating, Inspection, Packing. |
| Packing | IN BULK: carton, pallet, Small Boxes or customer request |
| Surface Coating | Black Oxide, Cadmium, Galvanized, Teflon, Xylan, Zinc, Others Upon Request |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Stud Bolts in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 600 Stud Bolts find extensive use in industries that demand high resistance to corrosion and heat. They are particularly suited for chemical processing equipment, heat exchangers, furnace components, and steam generators. In the power generation field, these bolts are essential for boiler systems and turbine exhaust structures. The aerospace and marine sectors depend on them for secure fastening in environments that face high temperatures and corrosive conditions. With their outstanding oxidation resistance and long-lasting durability, Inconel 600 Stud Bolts provide reliable performance and safety in even the most challenging industrial and thermal environments.
