Wai Nickel Alloys is a well-respected manufacturer and supplier located in Naypyidaw, Myanmar. They specialize in high-quality Inconel Forged Fittings that are engineered to perform exceptionally well in extreme temperatures and harsh, corrosive environments. These fittings are made from nickel-chromium-based superalloys, which provide remarkable strength, durability, and resistance to oxidation and chemical attacks. Wai Nickel Alloys takes pride in their precision forging, ensuring accurate dimensions and adherence to international quality standards. Their Inconel Forged Fittings are commonly utilized in the aerospace, petrochemical, and marine industries, where reliability and mechanical stability are crucial.
The composition of Inconel Forged Fittings primarily includes about 70% nickel and 14–17% chromium, along with added elements like molybdenum, niobium, titanium, and iron to boost their mechanical properties and corrosion resistance. This unique blend results in impressive tensile strength (up to 850 MPa), excellent oxidation resistance, and remarkable stability at temperatures reaching up to 1000°C. Additionally, these fittings are highly resistant to chloride-induced stress-corrosion cracking, pitting, and crevice corrosion, making them perfect for aggressive chemical and marine environments.
| Specifications | ASTM B564 & ASME SB564 |
| Standard | ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799 |
| Size | 1/8” NB to 4” NB (Socketweld & Screwed-Threaded) |
| Grades | Inconel 600, 601, 625, 718, 783, 690, X750 Forged Fittings |
| Type | Socketweld Fittings, Screwed-Threaded Fittings |
| Class | 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS |
| Grade | Ni | C | Mn | Si | S | Cu | Fe | Cr |
| Inconel 600 | 72.00 min | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 14.00 – 17.00 |
| Inconel 601 | 58.0 – 63.0 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 21.0 – 25.0 |
| Inconel 625 | 58.0 min | 0.10 max | 0.50 max | 0.50 max | 0.015 max | – | 5.0 max | 20.0 – 23.0 |
| Inconel 718 | 50.00 – 55.00 | 0.08 max | 0.35 max | 0.35 max | 0.015 max | 0.30 max | – | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
| Inconel 625 | 8.4 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 517 | 42.5 % |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel Forged Fittings in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele
Contact us to get a quick quote for your requirement.
Inconel Forged Fittings find extensive use in industries that operate under high-pressure and high-temperature conditions. Common applications include heat exchangers, pressure vessels, gas turbines, chemical processing units, power plants, and offshore platforms. They are also essential for connecting pipelines that transport corrosive fluids and gases in refineries and nuclear systems. With their impressive combination of strength, corrosion resistance, and temperature stability, Inconel Forged Fittings are the go-to choice for critical applications that demand safety, reliability, and long-lasting performance.
