Wai Nickel Alloys is a well-respected manufacturer and supplier of top-notch Inconel 601 Stud Bolts, proudly based in Naypyidaw, Myanmar. Renowned for its precision engineering and high-quality products, the company focuses on crafting corrosion-resistant and heat-resistant nickel alloy fasteners that are perfect for high-temperature and chemical processing settings. With cutting-edge manufacturing technology and a rigorous quality assurance process, Wai Nickel Alloys guarantees consistent performance, durability, and reliability in every single product. Industries like petrochemical, aerospace, marine, and power generation trust its Inconel 601 Stud Bolts for their remarkable mechanical strength and oxidation resistance, even in extreme operating conditions.
These Inconel 601 Stud Bolts are primarily made up of nickel (58–63%), chromium (21–25%), and iron (the balance), along with trace amounts of aluminum, silicon, and manganese. This unique composition provides outstanding resistance to oxidation, scaling, and carburization at temperatures reaching up to 1250°C. The alloy boasts impressive tensile strength of around 650 MPa and maintains high creep and rupture strength even at elevated temperatures. Aluminum contributes to surface stability, while the nickel-chromium matrix ensures excellent corrosion resistance in both oxidizing and carburizing environments, making them incredibly durable and reliable for high-temperature fastening needs.
| Specification | ASTM F468, B166 / ASME SF468, SB166 |
|---|---|
| Size | M02 to M33, Custom Sizes |
| Length | 3 mm to 200 mm |
| Stud Bolt | UNF, BSW, BSF, METRIC, UNC, or as required |
| Standard | DIN 525, DIN 835, DIN 938, DIN 939, DIN 940, DIN 949-1, DIN 949-2, DIN 975, DIN 976, DIN 2509, BS 2693, BS 3692, BS 4439, IS 1862, IS 13178, ANSI/ASME B18.31.2, ANSI/ASME B16.5 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Types | Stud Bolts, Fully Threaded Stud Bolts, Tap End Stud Bolts, Double End Stud Bolts, Stud Bolts with Reduced Shank, Reduced Shank, Flange Stud Bolts, Flange Bolting, Weld Studs |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Test Certificate | as per EN 10204 / 3.1 Manufacturer Test Certificate |
| Additional Certifications | PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Production process | M24-M100: hot forging, M2-M24: Cold Froging, for custom-made connecting element machining and CNC |
| Head drive of Stud Bolts | Six-Lobe, Phillips, Phillips/Slot, Slotted etc |
| Packing of Stud Bolts | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Ptfe Coated Phosphate Coating Teflon Coating Zinc Coating Hot Dipped Galvanizing Coating Cadmium Coating Xylon Coating |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 601 | 0.10 max | 1.0 max | 0.5 max | 0.015 max | 1.0 max | Balance | 58.0 – 63.0 | 21.0 – 25.0 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 601 | 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 601 Stud Bolts in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 601 Stud Bolts find their place in industries that require exceptional mechanical strength and oxidation resistance at high temperatures. They’re perfect for use in furnaces, heat exchangers, petrochemical processing units, and gas turbines. In the power generation sector, these bolts are essential for boiler systems, exhaust structures, and high-temperature piping. The marine and aerospace industries depend on them for secure fastening in corrosive and high-heat conditions. With their outstanding metallurgical stability, corrosion resistance, and long service life, Inconel 601 Stud Bolts deliver dependable performance in even the most challenging industrial environments.
