Wai Nickel Alloys, a leading manufacturer and supplier located in Naypyidaw, Myanmar, specializes in high-performance Nimonic 90 Sheets and Plates. These products are crafted for outstanding strength, durability, and resistance to oxidation, even at high temperatures. Made from a Nickel-Chromium-Cobalt alloy, with enhancements from Titanium and Aluminum, they’re perfect for components that face extreme stress and heat. Nimonic 90 Sheets and Plates excel in demanding industries like aerospace, power generation, and automotive engineering. With meticulous manufacturing and rigorous quality checks, Wai Nickel Alloys guarantees that every Nimonic 90 product meets international standards for mechanical integrity, corrosion resistance, and long-lasting reliability under thermal stress.
Nimonic 90 Sheets and Plates are made up of Nickel (≥60%), Chromium (18–21%), and Cobalt (15–20%), along with controlled amounts of Titanium (~2.5%), Aluminum (~1.5%), and trace elements of Carbon and Iron. This alloy boasts a tensile strength of 1000–1100 MPa and a yield strength of around 750 MPa, maintaining excellent mechanical properties even at temperatures up to 950°C. It shows impressive resistance to creep, fatigue, and oxidation, while also being easy to weld and form. The alloy’s stability under cyclic thermal loading makes it a top choice for components that need to be structurally reliable at high temperatures.
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Shims Thickness : | Range from .01″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Plate, Sheet and Strip : | BS HR 203, DIN 17750, AECMA PrEN2293, AECMA PrEN2302, AECMA PrEN2411, ISO 6208 |
| Grade | Ni | Cr | Co | Ti | Al | C | Si | Cu | Fe | Mn | B | S | Zr | Pb |
| Nimonic 90 | Bal | 18-21 | 15-21 | 2-3 | 1-2 | 0.2 max | 1.0 max | 0.2 max | 1.5 max | 1.0 max | 0.02 max | 0.015 max | 0.15 max | 0.0020 max |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 1150 MPa | 725 MPa | 30% |
| Grade | Density | Specific Gravity | Specific Heat (Btu/lb/Deg F – [32-212 Deg F]) | Electrical Resistivity (microhm-cm (at 68 Deg F) | Melting Point (Deg F) |
| Alloy 90 | 8.18g/cm³ | 1370°C | 12.7 μm/m °C (20 – 100°C) | 82.5 kN/mm² | 213 kN/mm² 227 / 240 kN/mm² |
| 0.296 lb/in³ | 2500°F | 7.1 x 10-6 in/in °F (70 – 212°F) | 11966 ksi | 30894 ksi 32924 / 34810 ksi |
| STANDARD | WERKSTOFF NR. | UNS |
| Nimonic 90 | 2.4632 | N07090 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nimonic 90 Sheets and Plates find extensive use in aerospace, turbine, and power generation sectors thanks to their exceptional high-temperature performance. They are often used in the production of gas turbine blades, discs, rings, combustion chambers, and exhaust components. In the automotive and chemical processing industries, they are utilized in valves, fasteners, heat exchangers, and furnace parts that are subjected to continuous heat and stress. Their ability to retain mechanical strength and resist oxidation under harsh conditions makes Nimonic 90 Sheets and Plates the go-to choice for many applications.
