Home > Super Duplex Steel > Super Duplex Steel Stud Bolts S32760
Wai Nickel Alloys is a leading manufacturer and supplier of Super Duplex Steel Stud Bolts S32760 in Naypyidaw, Myanmar. Our S32760 stud bolts are engineered to deliver superior performance in the most challenging environments, offering exceptional strength, corrosion resistance, and durability. Ideal for use in the oil and gas industry, chemical processing, and marine applications, these stud bolts are designed to withstand extreme conditions, including exposure to seawater and aggressive chemicals. With a strong commitment to quality and precision, Wai Nickel Alloys ensures that each product meets international standards, providing our clients with reliable fastening solutions for critical operations. Trust us for high-quality Super Duplex Steel Stud Bolts that deliver long-lasting results.
Wai Nickel Alloys, based in Naypyidaw, Myanmar, has built a solid reputation as a manufacturer and supplier of **Super Duplex Steel S32760 Stud Bolts**. These bolts are celebrated for their impressive mechanical strength, outstanding corrosion resistance, and durability. Crafted with precision from high-quality Super Duplex stainless steel and utilizing advanced manufacturing techniques, they guarantee dimensional accuracy, reliability, and long-lasting performance. Wai Nickel Alloys ensures that their Super Duplex Steel S32760 Stud Bolts meet international standards, making them perfect for critical applications in tough and corrosive environments.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32760 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32760 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
These **Super Duplex Steel S32760 Stud Bolts** consist of about 25% chromium, 7% nickel, 3.6% molybdenum, along with some tungsten and nitrogen. This well-balanced ferritic-austenitic microstructure offers remarkable resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. The material boasts high tensile strength (around 800–900 MPa), excellent fatigue resistance, and superior weldability. It remains stable and tough even at extreme temperatures, making it ideal for demanding operational conditions.
Contact us to get a quick quote for your requirement.
You’ll find **Super Duplex Steel S32760 Stud Bolts** widely used across various industries, including oil and gas, chemical processing, marine, desalination, and power generation. They are particularly suited for offshore platforms, heat exchangers, pressure vessels, and subsea pipelines, where strength and corrosion resistance are paramount. These stud bolts excel in chloride-rich and acidic environments, ensuring secure fastening and long-term durability. With Super Duplex Steel S32760 Stud Bolts, you can count on reliability, safety, and cost-effective performance, even in the most challenging industrial settings.
