Home > Super Duplex Steel > Super Duplex Steel Stud Bolts S32750
Wai Nickel Alloys is a leading manufacturer and supplier of Super Duplex Steel Stud Bolts S32750 in Naypyidaw, Myanmar. Renowned for their exceptional strength and corrosion resistance, our S32750 stud bolts are designed to meet the stringent demands of various industries, including oil and gas, chemical processing, and marine applications. With a commitment to quality and precision, we ensure that each stud bolt delivers superior performance in harsh environments, offering reliable and long-lasting fastening solutions. As a trusted supplier, Wai Nickel Alloys is dedicated to providing high-quality products that adhere to international standards, ensuring that our clients receive the best-in-class solutions for their critical applications.
| Specification | ASTM F593, F594, F1554 / ASME SF593, F594, F1554 |
| Standard | DIN : DIN 934, DIN 931, DIN 970, DIN 933 UTS : UNEF, NPT, UNC, UNS, UNF, NPTF ISO : JIS standards, ISO 4033, ISO 4032, ANSI – American National Standards Institute ASME B18.5 ANSI B 28.2.4 1M as per defined in ASME B16.5 standard Monel Monel® Alloy 400 Stud nuts length ANSI B 18.2.4 2M as per defined in ASME B18.2.2 Monel Alloy 400 Hex nuts |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Length | 3 mm to 200 mm | Custom Sizes |
| Dimensions | DIN 931, 933, 934, 7991, 976, 125, ASME B18.2.1, B18.3 |
| Form | Hex, Threading, Square, Round as per Gauge Etc. |
| Threads | Unless otherwise specified, the threads shall be rolled or cut and tapped horizontally or vertically |
| Threads available | UNF, BSW, BSF, METRIC, UNC, or as required |
| Threads Configuration | ASME B1.1 2A/3A – 2B/3B Inch Unified Threads and B1.13M 6h-6G Metric Coarse Threads |
| Certification | Dual Certified As per ASTM & ASME Codes |
| Test Certificate | As per EN 10204 / 3.1 Manufacturer Test Certificate, PED 97/23/EC Certified, Merkblatt AD 2000 W2 Certified |
| Raw materials Source | JSPL, Mukund Steel, Tata Steel, Dhamm Steel, Usha Martin,etc. |
| Packing | IN BULK: canton, pallet, Small Boxs / carton / pallet, or customer request |
| Surface Coating | Cadmium Coating Hot Dipped Galvanizing Coating Ptfe Coated Nickel Alloy 200 Fasteners Phosphate Coating Teflon Coating Xylon Coating Zinc Coating |
| Grade | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| Super Duplex Steel Stud Bolts S32750 | 0.030 max | 0.24 – 0.32 | 0.035 max | 0.80 max | 1.20 ma | 3.0 – 5.0 | – | 24.0 – 26.0 | 0.020 max | 6.00 – 8.00 |
| Grade | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| Super Duplex Steel Stud Bolts S32750 | 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
These **Super Duplex Steel S32750 Stud Bolts** consist of about 25% chromium, 7% nickel, 4% molybdenum, and a touch of nitrogen, resulting in a well-balanced austenitic-ferritic microstructure. This unique blend provides exceptional resistance to pitting, crevice corrosion, and stress corrosion cracking caused by chlorides. The alloy boasts impressive tensile strength (around 800–900 MPa), excellent yield strength, and superior resistance to fatigue and impact. Plus, it maintains great weldability, oxidation resistance, and structural stability, even in extreme temperatures and pressures.
Contact us to get a quick quote for your requirement.
You’ll find **Super Duplex Steel S32750 Stud Bolts** widely used across various industries, including oil and gas, petrochemical, marine, power generation, and desalination. They’re particularly suited for offshore platforms, pressure vessels, heat exchangers, and pipeline systems that face seawater and harsh chemical conditions. These bolts are also essential in the chemical processing and paper & pulp industries, where both strength and corrosion resistance are crucial. With **Super Duplex Steel S32750 Stud Bolts**, you can count on secure fastening, long-lasting reliability, and cost-effective performance in the most demanding industrial applications.
