Home > Rene 41 Sheets and Plates
Wai Nickel Alloys, a reputed manufacturer and supplier based in Naypyidaw, Myanmar, offers superior-quality Rene 41 Sheets and Plates designed for extreme high-temperature and high-stress environments. Renowned for their excellent strength, oxidation resistance, and thermal stability, these sheets and plates are crafted using advanced manufacturing techniques to ensure precision and reliability. Rene 41, a nickel-based superalloy, maintains exceptional mechanical properties even at temperatures up to 1800°F (982°C). These products are ideal for aerospace, gas turbine, and industrial applications requiring long-term performance, creep resistance, and structural integrity under the most demanding operating conditions.
Rene 41 Sheets and Plates are composed of Nickel (balance), Chromium (18–20%), Cobalt (10–12%), Molybdenum (9–10.5%), and Titanium (3–3.3%), with additions of Aluminum, Iron, and Carbon. The alloy offers a tensile strength of about 1000 MPa and yield strength near 750 MPa, along with excellent creep resistance and oxidation protection at elevated temperatures. It maintains outstanding hardness, fatigue strength, and thermal stability, ensuring superior resistance to corrosion and deformation under extreme thermal cycling, making it ideal for high-temperature industrial and aerospace applications.
| Standard Specification : | AMS 5545, AMS 5712, AMS 5713, AMS 5800, EN 2.4973, GE B50T59, GE B50TF109, GE B50TF76, UNS N07041, Werkstoff 2.4973 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Cr | Ni | Mo | Co | Al | Ti | B | C | Fe | Mn | Si | S | Cu | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| MIN | 18.00 | — | 9.00 | 10.00 | 1.40 | 3.00 | 0.003 | — | — | — | — | — | — |
| MAX | 20.00 | Balance | 10.50 | 12.00 | 1.80 | 3.30 | 0.01 | 0.12 | 5.00 | 0.10 | 0.50 | 0.015 | 0.50 |
| Mechanical & Physical Properties | 21°C | 427°C | 538°C | 649°C | 760°C | 871°C | 982°C |
|---|---|---|---|---|---|---|---|
| Ultimate Tensile Strength /MPa | 1261.7 | – | – | 1117 | 1048 | 710.2 | – |
| 0.2% Yield Strength /MPa | 820.5 | – | – | 765.3 | 751.5 | 579.2 | – |
| Elongation % | 21 | – | – | 14 | 14 | 11 | – |
| Coefficient of Thermal Expansion µm/m⁰C | – | 13.3 | 13.7 | 14.3 | 15.1 | 15.5 | 16.7 |
| Thermal Conductivity /kcal/(hr.m.°C) | – | 14.4 | 16.1 | 17.9 | 19.6 | 21.4 | – |
| Modulus of Elasticity / x105 MPa | – | 2 | 1.93 | 1.79 | 1.72 | 1.65 | 1.52 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Rene 41 Sheets and Plates are widely used in applications requiring high strength and oxidation resistance at elevated temperatures. In the aerospace industry, they are utilized for manufacturing turbine blades, jet engine components, and afterburner parts. In the power generation sector, they are used in gas turbines and combustion chambers exposed to extreme heat. The chemical and petrochemical industries employ them in heat exchangers, reactors, and high-pressure vessels. Additionally, Rene 41 Sheets and Plates are suitable for automotive, defense, and industrial furnace applications, offering outstanding performance, durability, and reliability in harsh, high-temperature environments.
