Wai Nickel Alloys, a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, specializes in top-notch Nickel Alloy 201 Bars. These bars are celebrated for their remarkable corrosion resistance, impressive thermal conductivity, and exceptional mechanical properties. Crafted from a low-carbon variant of commercially pure nickel, they offer enhanced resistance to graphitization at high temperatures. Nickel Alloy 201 Bars are perfect for high-temperature and high-purity settings where strength, stability, and chemical resistance are essential. With a commitment to precision and reliability, Wai Nickel Alloys serves industries like chemical processing, marine engineering, electronics, and aerospace, all of which demand outstanding durability and purity.
Nickel Alloy 201 Bars are composed of Nickel (≥99.6%) along with carefully controlled amounts of Copper, Iron, Manganese, Silicon, Carbon (≤0.02%), and Sulfur. The low carbon content boosts resistance to intergranular corrosion, making it suitable for temperatures exceeding 315°C. This alloy boasts a tensile strength of 370 MPa, a yield strength of 105 MPa, and an elongation of up to 40%. It maintains excellent ductility, malleability, and thermal conductivity, while also showing strong resistance to caustic alkalis and neutral salts. Nickel 201 preserves its structural integrity and oxidation resistance, even when continuously exposed to high temperatures.
| Nickel Bar Standard | ASTM B160, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Nickel Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Nickel Round bar size | Diameter: 3-~800mm |
| Nickel Hex Bar size | 2-100mm A/F |
| Nickel Alloy Flat bar size | Thickness: 2 -100mm |
| Width: 10 to 500mm | |
| Nickel Square bar size | 4 to 100mm |
| Alloy Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Nickel Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| ASTM B160 Type Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Nickel Alloy Threaded Bar Billet Size | 1/2 to 495mm Diameter |
| Nickel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| Alloy Hex Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Grade | Ni | Fe | C | Mn | Si | Cu | Mg | Ti | S |
|---|---|---|---|---|---|---|---|---|---|
| Nickel 201 | 99.0 min | 0.4 max | 0.02 max | 0.35 max | 0.2 max | 0.25 max | 0.15 max | 0.1 max | 0.01 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
|---|---|---|---|---|
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 201 Bars in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 201 Bars are widely utilized in the chemical and petrochemical sectors for producing caustic soda, as well as in heat exchangers and evaporators, thanks to their outstanding alkali resistance. They are also ideal for marine equipment, storage vessels, and piping systems that face corrosive environments. In the electronics industry, these bars are employed in battery connections, lead wires, and various electrical components due to their high conductivity and purity. Furthermore, Nickel Alloy 201 Bars are used in aerospace, power generation, and food processing equipment, showcasing their versatility and reliability.
