Wai Nickel Alloys is a leading manufacturer and supplier of Monel K500 tube fittings based in Naypyidaw, Myanmar. Our Monel K500 tube fittings are designed to offer outstanding strength, superior corrosion resistance, and high-temperature performance, making them ideal for demanding marine, aerospace, and industrial applications. Engineered for durability and reliability, these fittings excel in harsh environments and extreme conditions. We are committed to delivering precision-engineered solutions that meet the highest industry standards. Trust Wai Nickel Alloys for high-quality Monel K500 tube fittings that ensure long-lasting efficiency and resilience in critical applications.
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size Seamless 1/2″ – 10″ , Welded 1/2″ – 48″
Type (Seamless & 100% X-Ray Welded, Fabricated)
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade Monel K500 Pipe Fittings UNS (N05500), DIN (2.4375)
| NI | C | AL | MN | SI | FE | CU | S |
| 63.0 min | 0.3 max | 0.50 max | 2.0 max | 0.5 max | 1.0 – 2.5 | 28.0 – 34.0 | 0.02 max |
| DENSITY | MELTING RANGE | YIELD STRESS (0.2%OFFSET) | TENSILE STRESS | ELONGATION |
| 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 35,000 , MPa – 240 | Psi – 80,000 , MPa – 550 | 40 % |
**Monel K500 Tube Fittings** are made up of nickel (about 63%), copper (roughly 29–33%), along with trace amounts of aluminum and titanium. These components allow for precipitation hardening, which significantly boosts strength and hardness while keeping corrosion resistance intact. The alloy is known for its excellent resistance to seawater, acids, alkalis, and stress-corrosion cracking, all while maintaining toughness and ductility across a broad temperature range. Monel K500 not only retains the corrosion-resistant properties of Monel 400 but also enhances mechanical performance.
Contact us to get a quick quote for your requirement.
You’ll find **Monel K500 Tube Fittings** commonly used in marine engineering, oil and gas systems, chemical processing, and power generation. They’re perfect for tubing systems in heat exchangers, condensers, and hydraulic and instrumentation setups that deal with corrosive fluids under high pressure. The available types include compression, ferrule, elbow, tee, and union fittings. With their outstanding strength, corrosion resistance, and long service life, Monel K500 Tube Fittings provide dependable performance in critical and demanding environments.
