Wai Nickel Alloys is a premier manufacturer and supplier based in Naypyidaw, Myanmar, specializing in high-quality nickel alloys and Monel coils. With a commitment to excellence and innovation, we provide a diverse range of products tailored to meet the demanding needs of various industries. Our Monel coils, renowned for their superior corrosion resistance, high strength, and durability, deliver exceptional performance in challenging environments. Partner with us for reliable solutions and unmatched service in nickel alloys.
Monel coils are composed primarily of nickel (63-70%) and copper (28-34%), with small amounts of iron, manganese, and other elements. They exhibit excellent corrosion resistance, particularly in marine environments, and resist acidic and alkaline solutions. Monel coils are known for their high strength, durability, and resistance to stress corrosion cracking. Their properties include good thermal conductivity, high melting point, and ease of fabrication. These coils are advantageous for use in harsh environments where durability and resistance to corrosion are crucial.
| Specifications | ASTM B127 / ASME SB 127, BS EN 10088-2, en 10028-7, IS 6911 |
| Dimensions | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Size Range | Cold Rolled : 0.5-6.4 mm Hot Rolled : 3.0–10.0 mm |
| Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Thickness | 0.3 mm to 120 mm |
| International Standard of Sheets | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness | EN 10258/ DIN 59381 EN 10151 EN 10088 |
| Finish | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, soft annealed, descaled, sheared, annealed |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| C | Mn | Si | S | Cu | Fe | Ni | |
| Monel Coils | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | |
| Monel Coils | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel Coils in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel coils, made from a nickel-copper alloy, are renowned for their exceptional resistance to corrosion, high strength, and durability. They are widely used in marine environments, chemical processing, and aerospace applications where resistance to seawater and aggressive chemicals is crucial. Monel coils are also utilized in oil and gas industries, power generation, and for making components like valves, pumps, and fittings due to their ability to withstand harsh conditions and high temperatures. Their strength and corrosion resistance make them ideal for critical and demanding applications.
