Wai Nickel Alloys is a well-respected manufacturer and supplier of Monel 400 Coils, proudly based in Naypyidaw, Myanmar. The company has built a solid reputation for providing top-notch coils that boast remarkable strength, corrosion resistance, and durability. Their Monel 400 Coils are a go-to choice in various industrial sectors, thanks to their outstanding performance in both acidic and alkaline environments. With a strong focus on innovation, precision, and customer satisfaction, Wai Nickel Alloys guarantees that each product adheres to international quality standards, making them a reliable partner for clients in industries like marine engineering, chemical processing, and power generation.
Monel 400 Coils are made up of about 63% nickel and 30–34% copper, along with trace amounts of iron, manganese, silicon, and carbon. This special blend gives them excellent corrosion resistance in seawater, hydrofluoric acid, and alkalis. On the mechanical side, Monel 400 boasts a tensile strength of around 550 MPa and a yield strength of 240 MPa, along with a high elongation rate of 30–40%. The alloy maintains its toughness and ductility across a wide range of temperatures, ensuring reliability and performance even in the most extreme operating conditions.
Monel 400 Coils Specifications | ||
| Specifications | ASTM / ASME SB 127 | |
| Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm | |
| Thickness | 0.1mm to 12 mm Thk | |
| Form | Coils, Foils, Rolls, Plain Coil, Shim Coil, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Hot rolled Coil (HR), Cold rolled Coil (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. | |
| Grade | C | Mn | Si | S | Cu | Fe | Ni |
| Monel 400 | 0.30 max | 2.00 max | 0.50 max | 0.024 max | 28.00 – 34.00 | 2.50 max | 63.00 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Monel 400 | 8.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80,000 , MPa – 550 | Psi – 35,000 , MPa – 240 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Monel 400 Coils in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Monel 400 Coils are widely utilized in industries that demand superior corrosion resistance and mechanical strength. You’ll find them in marine engineering components like pump shafts, seawater valves, and heat exchangers. They’re also essential in chemical and hydrocarbon processing equipment, including piping systems, evaporators, and pressure vessels. Additionally, Monel 400 is used in the aerospace, oil refining, and power generation sectors due to its excellent thermal conductivity and resistance to stress-corrosion cracking, ensuring a long service life and consistent performance in challenging environments.
