Wai Nickel Alloys stands out as a reliable manufacturer and supplier of Inconel 600 Tubing in Naypyidaw, Myanmar. They’re well-regarded for providing top-notch nickel-based alloys that excel in extreme conditions. The Inconel 600 Tubing they produce is known for its remarkable resistance to oxidation, corrosion, and high-temperature scaling. Crafted with cutting-edge technology and rigorous quality standards, these tubes promise exceptional strength and durability. Wai Nickel Alloys serves a variety of industrial sectors, including chemical processing, aerospace, marine, and power generation, offering dependable and high-performance tubing solutions that meet the demands of challenging applications.
When it comes to composition and mechanical properties, Inconel 600 Tubing is primarily made up of nickel (at least 72%), chromium (14–17%), and iron (6–10%), along with trace amounts of manganese, silicon, and copper. This unique blend gives it excellent resistance to chloride-ion stress corrosion cracking and carburization. The alloy boasts a tensile strength of about 550 MPa, a yield strength of 240 MPa, and an elongation of 30%, ensuring it maintains high strength and toughness across a broad temperature range. These mechanical properties make it suitable for both cryogenic and high-temperature environments.
| Specifications | : | ASTM B163, B516 / ASME SB163, B516 |
| Dimensions | : | ASTM, ASME and API |
| Alloy 600 Tubes Size | : | 6 mm OD x 0.7 mm to 50.8 mm OD x 3 mm thk. |
| Schedule | : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Type | : | Seamless / ERW / Welded / Fabricated / LSAW Tubes |
| Form | : | Round, Square, Rectangular, Hydraulic Etc |
| Length | : | Single Random, Double Random & Cut Length. |
| End | : | Plain End, Beveled End, Treaded |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 600 Tubing in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
In terms of uses and applications, Inconel 600 Tubing is a go-to choice in industries that demand superior heat and corrosion resistance. You’ll find it in steam generators, heat exchangers, chemical process equipment, and nuclear reactors. Its outstanding performance in both oxidizing and reducing conditions makes it perfect for aerospace engine components, furnace retorts, and thermocouple sheaths. In the marine and power generation sectors, it’s effectively utilized in boiler feedwater heaters and condensers. With its combination of mechanical strength, oxidation resistance, and stability, Inconel 600 Tubing is a trusted option for harsh and high-temperature service environments.
