Wai Nickel Alloys is a leading manufacturer and supplier of Inconel 600 sheets and plates based in Naypyidaw, Myanmar. Our Inconel 600 sheets and plates are engineered to offer exceptional resistance to oxidation, corrosion, and high temperatures, making them ideal for challenging industrial environments. Perfect for use in chemical processing, heat exchangers, and furnace components, these products ensure long-term durability and performance. Committed to excellence, Wai Nickel Alloys provides tailored solutions to meet your specific requirements, delivering top-quality Inconel 600 sheets and plates designed to withstand the most demanding conditions.
| 600 Sheets & Plates Specifications | ASTM B168 / ASME SB168, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| 600 Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Alloy 600 Sheets & Plates Size Range | Cold rolled ASME SB168 Grade 600 Inconel Sheet 0.5-6.4 mm Hot rolled ASME SB168 Grade 600 Inconel Sheet 3.0–10.0 mm |
| 600 Inconel Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Inconel 600 Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Inconel 600 Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Inconel 600 Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Inconel 600 Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB168 600 Inconel Strips EN 10088 SA -240-600 Strips |
| Finish of Inconel 600 Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Inconel 600 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 600 | 0.15 max | 1.00 max | 0.50 max | 0.015max | 0.50 max | 6.00 – 10.00 | 72.00 min | 14.00 – 17.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 600 | 8.47 g/cm3 | 1413 °C (2580 °F) | Psi – 95,000 , MPa – 655 | Psi – 45,000 , MPa – 310 | 40 % |
The **Inconel 600 Sheet and Plates** are primarily made up of nickel, chromium, and iron, which work together to provide exceptional resistance to oxidation, chloride-ion stress-corrosion cracking, and carburization. This alloy maintains its strength and ductility even at elevated temperatures, showcasing high tensile and yield strength. Additionally, it offers good weldability, workability, and thermal stability, making it an excellent choice for high-performance and high-stress applications.
Contact us to get a quick quote for your requirement.
You’ll find **Inconel 600 Sheet and Plates** commonly used in heat exchangers, furnace components, chemical processing equipment, and nuclear reactors. They’re also essential in aerospace and marine environments where resistance to oxidation and scaling is crucial. Their ability to perform reliably in both oxidizing and reducing conditions makes Inconel 600 Sheet and Plates a go-to option for industries that require durability, reliability, and top-notch corrosion resistance in extreme operating conditions.
