Wai Nickel Alloys, a reputable manufacturer and supplier located in Naypyidaw, Myanmar, specializes in high-quality Tungsten Foil that excels in high-temperature and high-density applications. Known for its impressive strength, corrosion resistance, and thermal conductivity, the Tungsten Foil from Wai Nickel Alloys is meticulously crafted to adhere to global industrial standards. The company guarantees top-notch quality through cutting-edge production methods and thorough inspection processes. Offered in a range of thicknesses and sizes, their Tungsten Foil is perfect for critical sectors like electronics, aerospace, lighting, and defense, where durability, stability, and heat resistance are crucial for dependable, long-lasting performance.
Tungsten Foil is made up of at least 99.95% pure tungsten, boasting an impressive density of 19.3 g/cm³ and a melting point of 3420°C, the highest of any metal. It showcases remarkable thermal conductivity, low vapor pressure, and strong resistance to deformation, even at high temperatures. Mechanically, it provides high tensile strength, exceptional stiffness, and minimal creep under stress. The foil retains its structural integrity in harsh conditions, offering excellent wear resistance, hardness, and chemical stability—making it the go-to choice for extreme heat and vacuum applications.
| Standard Specification : | ASTM B760 / ASME SB760 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
| Thickness | Width | Length |
|---|---|---|
| 0.05-0.1 | 100 | L |
| 0.10-0.15 | 100 | 200 |
| 0.15-0.20 | 205 | 1000 |
| 0.20-0.25 | 300 | 1000 |
| 0.25-0.30 | 330 | 1000 |
| 0.30-0.50 | 350 | 1000 |
| 0.50-0.80 | 330 | 1000 |
| 0.80-1.0 | 330 | 1000 |
| 1.-1.50 | 300 | 1000 |
| 1.50-3.0 | 300 | 1000 |
| >3.0 | 300 | L |
Tungsten Foil finds extensive use in industries that require exceptional heat resistance and mechanical strength. It plays a vital role in semiconductor and electronic applications, such as vacuum furnace liners, heat shields, and cathode materials. In the lighting sector, it is essential for filament supports and electrodes. The aerospace and defense industries utilize Tungsten Foil for high-temperature shielding and propulsion components. Additionally, it is used in medical imaging equipment, X-ray shielding, and thin-film deposition processes. Its stability under extreme conditions makes it a reliable choice across various applications.
