Wai Nickel Alloys, a trusted manufacturer and supplier based in Naypyidaw, Myanmar, specializes in producing premium-quality Nimonic 80A Bars engineered for superior performance under high-temperature and high-stress conditions. This Nickel-Chromium alloy, strengthened with Titanium, Aluminum, and Carbon, offers exceptional oxidation resistance, creep strength, and thermal stability. Nimonic 80A Bars are ideal for use in aerospace, automotive, and power generation applications where strength and durability are paramount. Wai Nickel Alloys ensures that every product meets international standards, combining advanced manufacturing techniques and rigorous quality assurance to deliver materials that perform reliably in demanding environments.
Nimonic 80A Bars are composed of Nickel (≥70%), Chromium (18–21%), with controlled additions of Titanium (2.3%), Aluminum (1.4%), Carbon, and trace elements. The alloy provides a tensile strength of 950–1050 MPa and a yield strength around 700 MPa, maintaining excellent mechanical stability up to 980°C. It offers superior creep and fatigue resistance, excellent oxidation resistance, and high hardness and ductility. The combination of strength, heat resistance, and corrosion resistance ensures reliable performance in prolonged high-temperature operations and mechanically demanding conditions.
| Standards : | Nimonic 80A Rod, Bar : BS 3076 HR1, ASTM B 637, AECMA PrEn2188, AECMA PrEn2189, AECMA PrEn 2190, AECMA PrEn 2396, AECMA PrEn2397, AIR 9165-37 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | Al | B | C | Cr | Co | Cu | Fe | Mn | Ni | P | Si | S |
| Nimonic 80A | 1 – 1.8 | 0.008 max | 0.1 max | 18 – 21 | 0.2 max | 0.2 max | 3 max | 1 max | Balance | 0.045 max | 1 max | 0.015 max |
| Grade | Condition | Ultimate Tensile Strength MPA | Yield Strength MPA | Elongation on 4D (min) | Hardness min |
| Nimonic 80A | Solution Annealed & Precipatation Treated (aged) | 994 | 616 | 20 | 300 HV |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic 80A Bar in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nimonic 80A Bars are extensively used in industries that require exceptional mechanical strength and oxidation resistance at high temperatures. In the aerospace industry, they are employed in turbine blades, rings, fasteners, and exhaust systems. The power generation sector uses them for boilers, turbine components, and heat exchangers. In automotive and chemical processing industries, they are ideal for valves, furnace parts, and engine components exposed to intense heat and corrosive conditions. Their durability and performance make Nimonic 80A Bars the preferred material for applications demanding reliability, strength, and thermal stability.
