Wai Nickel Alloys, a leading manufacturer and supplier in Naypyidaw, Myanmar, offers high-performance Nickel Alloy 200 Stud Bolts engineered for superior corrosion resistance and mechanical reliability. Made from commercially pure wrought nickel, these stud bolts are designed to perform efficiently in harsh chemical, marine, and high-temperature environments. Nickel Alloy 200 Stud Bolts provide excellent strength, ductility, and thermal stability while maintaining exceptional resistance to caustic alkalis and acidic media. Wai Nickel Alloys ensures precision manufacturing and strict adherence to international standards, supplying fastening solutions that deliver durability and consistent performance across critical industrial, electrical, and marine applications.
Nickel Alloy 200 Stud Bolts consist primarily of Nickel (≥99.6%), with trace amounts of Copper, Iron, Manganese, Silicon, Carbon, and Sulfur. This composition ensures superior resistance to alkaline and neutral salt environments. The alloy exhibits a tensile strength of about 370 MPa, yield strength of 105 MPa, and elongation of up to 40%, providing excellent ductility and formability. It performs reliably up to 315°C, maintaining thermal and electrical conductivity. Nickel 200’s low gas content and magnetic permeability make it ideal for precision and high-purity engineering environments.
| Grade | Nickel |
| Specifications | ASTM B 160/164, ASME SB 160/164 |
| Dimension | ASTM, IS, BS and all International Standards |
| Length | 3mm to 200mm |
| Size | M3 – M56 | 3/6″ to 2″ | Custom Sizes |
| Types | Threaded Rod, Class A double ended stud, Tie Rod, Double Ended Stud, Stud Bolts, Bronze Hex Studs, Threaded Studs etc etc. |
| Grade | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Nickel | 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Nickel | Balance | 0.15 max | – | 0.35 max | 0.35 max | 0.40 max | – | 0.01 max | 0.25 max | – |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nickel Alloy 200 Stud Bolts in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Nickel Alloy 200 Stud Bolts are extensively used in chemical processing plants, alkali manufacturing units, and food processing systems due to their outstanding corrosion resistance and purity. They are ideal for heat exchangers, storage vessels, evaporators, and piping systems exposed to caustic solutions. In the electrical and electronics sectors, these bolts are used for conductive assemblies, battery connections, and terminal fittings. Marine and power generation industries utilize them for their durability in saltwater and high-temperature environments. Their combination of strength, conductivity, and corrosion resistance makes them perfect for critical fastening applications in demanding environments.
