Home > Nickel Alloy > Nickel 200 Alloy Sheet and Plates
Wai Nickel Alloys is a leading manufacturer and supplier of Nickel Alloy 200 sheets and plates in Naypyidaw, Myanmar. Our Nickel Alloy 200 sheets and plates are designed to deliver superior strength, durability, and exceptional corrosion resistance, making them ideal for a wide range of industrial applications. Known for their performance in harsh environments, these sheets and plates are perfect for use in chemical processing, aerospace, marine, and oil and gas industries. We ensure each product meets stringent industry standards for quality and reliability. Choose Wai Nickel Alloys for premium Nickel Alloy 200 sheets and plates that provide outstanding performance and meet your specific requirements with precision and excellence.
| Nickel Alloy Sheets & Plates Specifications | ASTM B162 / ASME SB162, BS EN 10088-2, en 10028-7, IS 6911 |
|---|---|
| Nickel Alloy Sheets & Plates Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| Nickel Alloy Sheets & Plates Size Range | Cold rolled ASME SB162 Grade 201 Nickel Alloy Sheet 0.5-6.4 mm Hot rolled ASME SB162 Grade 200 Nickel Alloy Sheet 3.0–10.0 mm |
| Nickel Alloy Sheets & Plates Width | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Nickel Alloy Sheets & Plates Length | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Nickel Alloy Sheets & Plates Thickness | 0.3 mm to 120 mm |
| International Standard of Nickel Alloy Sheets & Plates | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Nickel Alloy Sheets & Plates | EN 10258/ DIN 59381) EN 10151 ASME SB162 200 Nickel Alloy Strips EN 10088 SA -240-400 Strips |
| Finish of Nickel Alloy Sheets & Plates | 2B, 2D, BA NO (8), Cold rolled sheet (CR), Hot rolled plate (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, hairline, brush, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Sheet, Plate, Strip, Flats, Clad Plate, Coils, Foils, Plain Sheet, Flat Shim, Flat Sheet, Shim Sheet, Rolling Sheet, Rolling Plate, Rolls, Blank (Circle), soft annealed, descaled, tread plate, sheared, annealed, Checker Plate |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Dealers & Distributor of | SAIL, ESSAR, JINDAL, TATA, BHUSHAN, INDIAN, POSCO, JISCO, TISCO, LISCO, BAOSTEEL IMPORTED material |
| Nickel Alloy Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
| Element | Ni+Co | Cu | Si | Mn | C | Mg | S | P | Fe |
|---|---|---|---|---|---|---|---|---|---|
| Nickel | 99.99 | 0.015 | 0.03 | 0.002 | 0.01 | 0.01 | 0.001 | 0.001 | 0.04 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Nickel | 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 67000 , MPa – 462 | Psi – 21500 , MPa – 148 | 45 % |
**Nickel Alloy 200 Sheet and Plates** are made up of around 99.6% pure nickel, which gives them fantastic resistance to caustic alkalis, neutral salts, and reducing chemicals. Thanks to their low carbon content, they maintain good ductility and avoid embrittlement. This alloy also boasts high thermal and electrical conductivity, favorable magnetic properties, and outstanding toughness across a wide temperature range. These characteristics make Nickel Alloy 200 an excellent choice for both high and low-temperature applications.
Contact us to get a quick quote for your requirement.
You’ll find **Nickel Alloy 200 Sheet and Plates** commonly used in chemical and petrochemical plants, marine engineering, food processing, and alkali production facilities. They’re perfect for creating heat exchangers, evaporators, pressure vessels, and equipment for handling caustic soda. Their ability to endure harsh chemical environments and high temperatures ensures they last a long time. With their superior strength, weldability, and formability, Nickel Alloy 200 Sheet and Plates are the go-to option for industries that need corrosion-resistant and high-performance materials.
