Home > Mu Metals Sheets and Plates
Wai Nickel Alloys, a leading manufacturer and supplier in Naypyidaw, Myanmar, offers high-quality Mu Metal Sheets and Plates designed for superior magnetic shielding and electronic protection. These precision-engineered materials are made from a high-permeability nickel-iron alloy that provides exceptional resistance to low-frequency magnetic fields. Mu Metal Sheets and Plates are carefully processed through controlled annealing to achieve maximum magnetic performance, ensuring excellent formability and durability. Wai Nickel Alloys supplies Mu Metal products to meet international standards, providing reliable solutions for industries such as electronics, medical instrumentation, telecommunications, and aerospace, where electromagnetic interference control is critical.
Mu Metal Sheets and Plates are composed primarily of Nickel (≈77%), Iron (≈16%), Copper (≈5%), and Molybdenum (≈2%), offering high magnetic permeability and low coercivity. The material achieves a relative permeability up to 100,000 after hydrogen annealing and maintains stability under varying magnetic and mechanical stresses. It has a tensile strength of around 370 MPa with excellent ductility, allowing easy fabrication and forming. Mu Metal retains magnetic performance across temperature variations, ensuring reliable shielding efficiency and structural integrity in demanding electromagnetic environments.
| Standard Specification : | |
| Dimensions : | – |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Mu Metal Sheets and Plates are widely used for magnetic shielding in sensitive electronic and scientific applications. They are employed in transformer cores, electronic housings, MRI equipment, medical imaging devices, laboratory instruments, and aerospace systems to minimize magnetic interference. In the telecommunications and defense sectors, Mu Metal protects delicate equipment from electromagnetic and magnetic field distortions. Additionally, it is used in audio devices, power distribution components, and precision measurement instruments to ensure signal stability and performance accuracy. Its unique ability to absorb and redirect magnetic fields makes Mu Metal indispensable in modern electromagnetic control systems.
