Wai Nickel Alloys is a well-respected manufacturer and supplier located in Naypyidaw, Myanmar. They specialize in high-quality Kovar Sheets and Plates, crafted for precision and performance in demanding industrial applications. These products are made from a nickel-cobalt-iron alloy that features controlled thermal expansion, making them perfect for sealing with glass and ceramics. Wai Nickel Alloys is committed to maintaining tight dimensional tolerances, delivering a superior surface finish, and adhering to international standards, ensuring reliability and consistency. Their Kovar Sheets and Plates are widely utilized in the electronics, aerospace, and instrumentation sectors, where thermal compatibility and high stability are essential.
The composition of Kovar Sheets and Plates includes about 29% nickel, 17% cobalt, and the remainder iron, along with trace amounts of manganese, silicon, and carbon. This specific blend provides a controlled coefficient of thermal expansion that aligns with borosilicate glass, as well as impressive tensile strength (around 520 MPa) and good ductility. The alloy retains its mechanical and magnetic stability even when subjected to fluctuating thermal conditions. Kovar also boasts excellent oxidation resistance in controlled environments and is easy to work with for forming, welding, and machining, making it a top choice for high-precision fabrication.
| Standard Specification : | UNS K94610 | Werkstoff Nr 1.3981 | DIN 17745 | ASTM F15 | AMS 7726 | AFNOR NF A54-301 | S.E.W 385 |
| Dimensions : | ASTM, ASME, and API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Chemical Analysis | |
| Cr | 20 nom |
| Ni | 35 nom |
| Mo | 10 nom |
| Co | 35 nom |
| Material | Condition | Yield Strength (0.1% Offset) | Tensile Strength | Elongation % | ||
|---|---|---|---|---|---|---|
| psi | MPa | psi | MPa | |||
| Alloy K Kovar | Annealed | 49,000 | 340 | 75,000 | 520 | 42 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Nimonic Sheet and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Kovar Sheets and Plates are extensively employed in applications that require hermetic sealing and dimensional stability. They are particularly suited for electronic components, vacuum tubes, transistors, semiconductor packaging, and glass-to-metal seals. In the aerospace and defense sectors, they find use in sensors, instrument housings, and electronic assemblies that experience thermal cycling. Their ability to match the thermal expansion of glass and ceramics, combined with high mechanical integrity, makes Kovar Sheets and Plates a preferred option for critical components in electronics, communication, and scientific instruments.
