Wai Nickel Alloys is a well-respected manufacturer and supplier located in Naypyidaw, Myanmar, specializing in high-quality Inconel 718 Pipe Fittings that are built to perform reliably in both high-pressure and high-temperature settings. These fittings are crafted from a nickel-chromium alloy, enhanced with niobium, molybdenum, and titanium, which gives them remarkable strength and resistance to corrosion. Wai Nickel Alloys takes pride in delivering precision-engineered fittings that adhere to international quality standards. Their Inconel 718 Pipe Fittings are commonly utilized in industries such as aerospace, chemical processing, marine, and power generation, where durability, performance, and oxidation resistance are essential.
The composition of Inconel 718 Pipe Fittings includes nickel (50–55%), chromium (17–21%), iron (the balance), along with trace amounts of molybdenum, niobium, titanium, and aluminum. This unique blend provides impressive tensile strength (up to 1375 MPa), excellent creep and rupture resistance, and outstanding oxidation resistance at temperatures reaching 700°C. The alloy’s precipitation-hardening properties contribute to high fatigue strength while still allowing for good weldability and formability. These characteristics make Inconel 718 an ideal choice for fittings that need to withstand extreme thermal and corrosive conditions.
Specifications : ASTM B564 & ASME SB564
Standard : ASME 16.11, MSS SP-79, 83, 95, 97, BS 3799
Size : 1/8” NB to 4” NB (Socketweld & Screwed-Threaded)
Class : 2000 LBS, 3000 LBS, 6000 LBS, 9000 LBS
Type: Socketweld Fittings, Screwed-Threaded Fittings
| Grade | C | Mn | Si | S | Cu | Fe | Ni | Cr |
| Inconel 718 | 0.08 max | 0.35 max | 0.35 max | 0.015max | 0.30 max | – | 50.00 – 55.00 | 17.00 – 21.00 |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Inconel 718 | 8.2 g/cm3 | 1350 °C (2460 °F) | Psi – 1,35,000 , MPa – 930 | Psi – 75,000 , MPa – 482 | 45 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Inconel 718 Pipe Fittings in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
Inconel 718 Pipe Fittings are extensively used in sectors that require reliable performance under harsh operating conditions. Common applications include jet engines, gas turbines, heat exchangers, and nuclear reactors. They are also found in chemical processing facilities, oil and gas refineries, and marine equipment, serving as connectors for pipelines and systems that encounter corrosive substances. The combination of mechanical strength, corrosion resistance, and temperature stability makes Inconel 718 Pipe Fittings a top choice for critical and high-performance piping applications.
