Wai Nickel Alloys, based in the heart of Naypyidaw, is a trusted source for high-performance materials, bringing global standards of quality to Myanmar’s industrial landscape. We specialize in providing advanced solutions like Haynes 25 (L605) foil, a material chosen by engineers who cannot compromise on performance. Our commitment is to supply this exceptional alloy with the reliability and precision that your most demanding projects require, ensuring you have a local partner you can count on for critical applications.
Haynes 25, also known as L605, is a cobalt-chromium-nickel-tungsten alloy celebrated for its remarkable strength. It maintains excellent tensile and creep rupture properties even when exposed to intense heat, up to 1800°F. This foil offers outstanding oxidation resistance, making it incredibly durable in harsh environments. While it is workable, it does require more attention during fabrication than standard steels. Its unique composition gives it a distinctive edge for situations where other high-temperature alloys might fall short.
| Standard Specification : | AMS 5759, AMS 5537 |
| Dimensions : | AMS, AMS, API |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat T |
| Grade | C% | Si≤ % | Mn≤ % | P≤ % | S≤ % | Cr% | Ni% | Co% | Fe % | W % |
| Haynes 25 / L605 | 0.05-0.15 | 0.40 | 2.00 | 0.02 | 0.015 | 19.0-21.0 | 9.00-11.0 | Rest | ≤ 3.00 | 14.0-16.0 |
| Grade | 0.2% Yield strength Rp ≥ N/mm² | Tensile strength Rm N/mm² | Elongation A5 | Resistant on air up to°C | Modulus of elasticity kN/mm² |
| Haynes 25 / L605 | 345 | 830-1130 | 25 | 1090 | 225 |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
The versatility of Haynes 25 L605 foil makes it indispensable across several advanced industries. You will find it forming the critical components of jet engines and gas turbines, where heat resistance is non-negotiable. It’s also essential in medical devices, particularly for implants and surgical tools that demand biocompatibility and reliability. Beyond these, this foil is used in heat-treating equipment, chemical processing systems, and even in the demanding environment of aerospace fasteners, proving its value wherever extreme conditions are the norm.
