Wai Nickel Alloys stands as a trusted source for high-performance materials right here in Naypyidaw, providing industries across Myanmar with reliable solutions for their most demanding applications. We take pride in supplying Haynes 230 sheets and plates, a premium alloy known for its exceptional strength and resilience. Our commitment is to deliver not just a product, but a partnership, ensuring you have the right material to build a stronger, more efficient future for your projects.
Haynes 230 is a nickel-chromium-tungsten-molybdenum alloy crafted for outstanding performance. It maintains remarkable strength and stability at high temperatures, resisting oxidation exceptionally well. This material is also highly ductile and offers good fatigue resistance, making it both tough and workable. Its balanced composition gives it an edge in harsh environments where other alloys might fail, providing a reliable combination of durability and thermal resistance for long-term use.
| Specification : | AMS 5878 |
| Standard : | AMS, AMS, API |
| Specialize sheets : | Shim, Perforated Sheet, B. Q. Profile. |
| Size : | 0.5 MM TO 200 MM THICK IN 1000 MM TO 2500 MM WIDTH & 2500 MM TO 12500 MM LENGTH |
| Finish : | Cold rolled sheet (CR), 2D, Hot rolled plate (HR), 2B, BA NO(8), SATIN (Met with Plastic Coated) |
| Hardness : | Quarter Hard, Soft, Hard, Half Hard, Spring Hard etc. |
| Grade : | Haynes 230 (UNS N06230) |
| Weight% | C | Mn | Si | P | S | Cr | Co | Fe | Al | Ti | B | Cu | La | W | Mo | Ni |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.25-0.75 | 0.03 | 0.015 | 20.0-24.0 | 5.0 | 3.0 | 0.20-0.50 | 0.10 | 0.015 | 0.50 | 0.005-0.05 | 13.0-15.0 | 1.0-3.0 | Rem |
| Material | Test Temp °F | Ultimate Tensile Strength | 0.2 % Yield Strength | Elongation in % | Hardness HB |
| Haynes Alloy 230 Extruded Bar Solution Treated (AMS 5891) | RT | 758 Mpa 110 ksi | 310 Mpa 45 ksi | 35 | 241 max |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Hastelloy Sheets and Plates in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
The versatility of Haynes 230 sheets and plates makes them ideal for critical components in sectors like aerospace, for combustion liners and transition ducts, and in industrial gas turbines. They are equally vital in thermal processing for heat-treating equipment and fixtures. In the chemical processing industry, this alloy is chosen for its resistance to corrosive atmospheres, proving essential in furnace systems, heat exchangers, and other high-temperature applications where reliability cannot be compromised.
