Wai Nickel Alloys is a trusted manufacturer and supplier based in Naypyidaw, Myanmar, specializing in high quality nickel alloys and other technical products With a commitment to excellence we provide offers a wide range of products including Haynes 230 bars. Haynes 230 bar is a high performance nickel-chromium alloy known for its excellent resistance to high temperature oxidation and carburization, making it ideal for harsh conditions in industries such as aerospace, chemical processing and in energy production.
The strength of Haynes 230 lies in its sophisticated composition, primarily nickel and chromium, fortified with tungsten and molybdenum. This unique blend grants it outstanding resistance to oxidation and maintains remarkable strength even when exposed to extreme temperatures. It’s an alloy that doesn’t just withstand heat; it performs consistently under intense thermal stress, making it a robust and dependable choice for engineers facing high-temperature challenges.
| Standards : | ASTM 5878, ASME S5878 |
| Dimensions : | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Wire : | Thickness starting from 0.05mm |
| Round bar size : | Diameter: 3-~800mm |
| Hex Bar size : | 2-100mm A/F |
| Flat bar size : | Thickness: 2 -100mm / Width: 10 to 500mm |
| Square bar size : | 4 to 100mm |
| Rectangular Bars Size : | 33 x 30mm to 295 x 1066mm |
| Hollow Bar : | 32mm OD x 16mm ID to 250mm OD x 200mm ID |
| Tolerance : | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Finish : | Black, Bright Polished, Rough Turned, NO.4 Finish, Matt Finish, BA Finish |
| Grade | C | Mn | P | S | Si | Ni | Cr | Fe | W | B | La | Co | Ai | Ti | Cu | La | Mo |
| Haynes 230 | 0.05-0.15 | 0.30-1.0 | 0.03 max | 0.015 max | 0.25-0.75 | Rem | 20.0-24.0 | 3.0 max | 13.0-15.0 | 0.015 max | 0.005-0.05 | 5.0 max | 0.20-0.50 | 0.10 max | 0.50 max | 0.005-0.05 | 1.0-3.0 |
| Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness HB |
| ksi – 758, MPa – 110 | ksi – 310, MPa – 45 | 35 % | 241 max |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of Haynes 230 Bar in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
This bar’s unique properties make it indispensable in sectors where failure is not an option. You’ll find it at the heart of gas turbine engines, industrial furnace components, and critical chemical processing equipment. Its ability to perform under fire also makes it ideal for aerospace applications and power generation systems. Essentially, wherever intense heat and corrosive environments are a daily reality, Haynes 230 provides the necessary resilience to ensure long-term, trouble-free operation.
