Located in the heart of Naypyidaw, Wai Nickel Alloys stands as a dedicated manufacturer and supplier committed to precision and reliability. We specialize in producing A286 Foil, a material engineered for demanding environments where failure is not an option. Our focus is on delivering a product that consistently meets the highest standards of quality, providing our clients with the confidence that comes from a trusted local source. We understand that the integrity of your projects depends on the materials you use, and we are here to ensure that foundation is solid.
The A286 alloy is an iron-nickel-chromium blend, strengthened with additions of molybdenum, titanium, and aluminum. This specific composition gives the foil its remarkable strength and resistance to high temperatures. It maintains excellent tensile and creep strength even when exposed to intense heat, while also offering good resistance to oxidation. Essentially, it’s a material designed not just to perform, but to endure under conditions that would cause ordinary metals to weaken or fail.
| Standard Specification : | AMS 5525, AMS 5858 |
| Dimensions : | AMS |
| Sheets Thickness : | Range from .008″ to .0125″ |
| Plates Thickness : | Ranges from .0125″ to 5.00″ |
| Sheets/Plates Width : | 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc |
| Sheets/Plates Length : | 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc |
| Tempers : | Annealed, 1/4, 1/2 Hard, 3/4 Hard, Full Hard |
| Hardness : | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Value Added Service : | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Grade | C | Mn | Si | S | Co | Cu | Ni | Cr | P | V | Al | B |
| A286 | 0.08 max | 2 max | 1 max | 0.025 max | 1 max | 0.50 max | 24 – 27 | 13.5 – 16 | 0.025 max | 0.10 – 0.50 | 0.35 max | 0.003 – 0.010 |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 7.92 g/cm3 | 2500-2600°F (1370-1430°C) | 90,000 psi (620MPa) | 40,000 psi (275 Mpa) | 40 % |
At Wai Nickel Alloys, we take pride in being the largest supplier, exporter, and manufacturer of A286 Foil in Naypyidaw, Myanmar, providing cutting-edge solutions for all your piping needs. Our state-of-the-art production plants are strategically located in the Myanmar, allowing us to maintain a vast inventory of over 16,000 tons of premium-quality materials readily available in stock. We are dedicated to delivering superior products and services, ensuring reliability and excellence for our global clientele.
Contact us to get a quick quote for your requirement.
The unique properties of A286 Foil make it indispensable across several advanced industries. You’ll find it forming critical components in jet engines and gas turbines, where it serves as seals, gaskets, and liners. In the automotive sector, it’s used in turbochargers and high-performance exhaust systems. Beyond aerospace and automotive, this foil is also vital in the manufacturing of specialized fasteners and springs for applications that must withstand both high stress and elevated temperatures, proving its versatility and critical role in modern engineering and innovation.
